Real time RGB graph from webcam

Question

I need to create a graphic that shows in real time RGB from a video. I know that I have to capture a frame and plot 3 channels in a graphic and in the axis x plot time. But I am having a error. Webcam opens normally and a blank graph is showed at the screen. Does someone has any ideas that how can I write this code?

import cv2
import matplotlib.pyplot as plt
import numpy as np
from matplotlib.animation import FuncAnimation

capture = cv2.VideoCapture(0)
ret, frame = capture.read()

fig = plt.figure()
ax1 = fig.add_subplot(1,1,1)


while True:
    ret, frame = capture.read()
    cv2.imshow('Frame', frame)

    if not ret:
        break


    def animate(i):

        b, g, r = cv2.split(frame)
        xs = []
        ys = []
        for line in b:
            if len(line) > 1:
                x, y = line.split(',') #Getting the error: 'numpy.ndarray has no attribute split'.
                xs.append(x)
                ys.append(y)
        ax1.clear()
        ax1.plot(xs, ys)


    ani = FuncAnimation(fig, animate, interval=1000)
    plt.show()

    keyval = cv2.waitKey(1) & 0xFF

    if keyval == ord('q'):
        break


capture.release()
cv2.destroyAllWindows()




Answer 1

You want to display an interactive graph while receiving webcam frames.

• 1. You can use plt.ion(). The ion() method updates the graph while receiving inputs.

  • You may ask Why not using FuncAnimation?

    • From what I understand FuncAnimation method is not designed for while loop. FuncAnimation is useful for pre-computed frames. Here you can see the example1 and example2.
• 2. How to get frames for each second?

  • We can calculate the fps (frame-per-second) value. For instance, if the fps value is 5, then 5 frames duration is equal to the 1 second.

  • We can count the frames using a variable and check whether the variable equals the fps. Then we add the frames.

    • if frame_count % fps == 0:
          b, g, r = cv2.split(frame)

          line = [line for line in zip(b, g, r) if len(line)]

          xs.append(second)
          blue.append(np.mean(line[0]))
          green.append(np.mean(line[1]))
          red.append(np.mean(line[2]))


    • You may ask Why not using time.time for calculating the seconds?

    • I think using fps is more reliable than using time.time. I wanted to guarantee to get frames for each second.

Result:

I've obtained the result from the command prompt. If you debug it, you may get multiple images instead of one updated image.

Update-1

---

If you want to separate the channels you can multiply the each calculated variance with a different coefficient:

blue.append(np.var(line[0])*0.02)
green.append(np.var(line[1])*0.03)
red.append(np.var(line[2])*0.04)

Result:

• You can also use np.mean

blue.append(np.mean(line[0])*0.02)
green.append(np.mean(line[1])*0.03)
red.append(np.mean(line[2])*0.04)

Result:

Update-2

---

If you want to write the output data to the excel, you can use the xlsxwriter library.

You can install:

---

• pip environment: pip install xlsxwriter
• anaconda environment: conda install -c anaconda xlsxwriter

Three-steps:

---

• Step1: Create worksheet:

  • book = Workbook('Channel.xlsx')
    sheet = book.add_worksheet()


• Step2: Initialize row and column variables:

  • row = 0
    col = 0


• Step3: Write

  • for s, b, g, r in zip(xs, blue, green, red):
        sheet.write(row, col, s)
        sheet.write(row + 1, col, b)
        sheet.write(row + 2, col, g)
        sheet.write(row + 3, col, r)
        col += 1


Output:

Update-3

---

• 1. Time

---

• In previous updates, the fps = cv2.CAP_PROP_FPS which was wrong. The correct usage is fps = capture.get(cv2.CAP_PROP_FPS). Now we are getting the webcam's fps.

• 2. Speeding-up

---

• We were using red, green, blue, xs list structures for storing frames and seconds for both displaying and writing to the excel file.

• As frame data increases the list structures become a burden for real-time processing. Therefore one solution is dividing the displaying and writing operations.

• For displaying: b_frame, g_frame, r_frame, and s_frame are used.

• For writing to excel: blue, green, red, and xs are used.

• The main advantage is now we can reduce the storage for displaying frames. Since we are storing in blue, green, red, and xs.

• For instance: after two seconds delete the first frames.

  del b_frame[0]
  del g_frame[0]
  del r_frame[0]
  del s_frame[0]


• Since the b_frame, g_frame, r_frame, and s_frame are no longer containing all the frames. The system speeds-up.

Update-4

---

VideoCapture blocks the application while the next frame is read, decode, and returned. Most probably this is the reason for the frozen camera.

One option is using VideoStream which process read, decode, and return actions concurrently by using queue structure.

To install imutils

---

• For pip: pip install imutils
• For anaconda: conda install -c conda-forge imutils

Example:

---

from imutils.video import VideoStream

vs = VideoStream().start()

while True:
    frame = vs.read()

    if frame is None:
        break

    .
    .


vs.stop()

I tested VideoStream and there were no frozen frames or pause during the application.

Code:

---

import cv2
import numpy as np
import matplotlib.pyplot as plt

from imutils.video import VideoStream
from xlsxwriter import Workbook

fig = plt.figure()

plt.ion()  # Set interactive mode on

xs = []
blue = []
red = []
green = []

b_frame = []
g_frame = []
r_frame = []
s_frame = []

# We will be using Video-capture to get the fps value.
capture = cv2.VideoCapture(0)
fps = capture.get(cv2.CAP_PROP_FPS)
capture.release()

# New module: VideoStream
vs = VideoStream().start()

frame_count = 0
second = 1

is_new_frame = False

while True:
    frame = vs.read()

    if frame is None:
        break

    if frame_count % int(fps) == 0:
        b, g, r = cv2.split(frame)

        is_new_frame = True  # New frame has come

        line = [line for line in zip(b, g, r) if len(line)]

        s_frame.append(second)
        b_frame.append(np.mean(line[0]) * 0.02)
        g_frame.append(np.mean(line[1]) * 0.03)
        r_frame.append(np.mean(line[2]) * 0.04)

        plt.plot(s_frame, b_frame, 'b', label='blue', lw=7)
        plt.plot(s_frame, g_frame, 'g', label='green', lw=4)
        plt.plot(s_frame, r_frame, 'r', label='red')
        plt.xlabel('seconds')
        plt.ylabel('mean')
        if frame_count == 0:
            plt.legend()
        plt.show()

        second += 1

    elif second > 2:

        if is_new_frame:

            if second == 3:
                blue.extend(b_frame)
                green.extend(g_frame)
                red.extend(r_frame)
                xs.extend(s_frame)
            else:
                blue.append(b_frame[len(b_frame)-1])
                green.append(g_frame[len(g_frame)-1])
                red.append(r_frame[len(r_frame)-1])
                xs.append(s_frame[len(s_frame)-1])

            del b_frame[0]
            del g_frame[0]
            del r_frame[0]
            del s_frame[0]

            is_new_frame = False  # we added the new frame to our list structure

    cv2.imshow('Frame', frame)

    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

    frame_count += 1

cv2.destroyAllWindows()
capture.release()
vs.stop()

book = Workbook('Channel.xlsx')
sheet = book.add_worksheet()

row = 0
col = 0

sheet.write(row, col, 'Seconds')
sheet.write(row + 1, col, 'Blue mean')
sheet.write(row + 2, col, 'Green mean')
sheet.write(row + 3, col, 'Red mean')

col += 1

for s, b, g, r in zip(xs, blue, green, red):
    sheet.write(row, col, s)
    sheet.write(row + 1, col, b)
    sheet.write(row + 2, col, g)
    sheet.write(row + 3, col, r)
    col += 1

book.close()
