Framework was built without full bitcode - Framework bitcode already enabled

Question

Getting this error on Archiving my app. Framework used is my own. So I cross checked. Bitcode in framework is Enabled. Not sure why am I getting this issue. These are the build settings in my framework :

I followed this link but didn't work. Tried to set -fembed-bitcode in framework's project (not target, but project, since it is recommended in the link) setting.

score 13 · Answer 1 · answered Dec 13 '18 at 10:04

Bitcode is an abstract encoding of an app that can be used to re-compile it in different ways, given a set of instructions. You can confirm whether your binary is bitcode-compatible by running :

otool -l (my .o or .a file) | grep __LLVM.

When you build normally, Xcode adds the build flag -fembed-bitcode-marker to any clang invocation.

To Add -fembed-bitcode: select project Build Settings -> Other C flags, set Debug to -fembed-bitcode-marker and Release to -fembed-bitcode this will build your lib with bitcode.

BITCODE_GENERATION_MODE

If you set BITCODE_GENERATION_MODE=bitcode on your User-defined Setting, even during the build phase, the files will be compiled using the flag -fembed-bitcode.

And, if you set BITCODE_GENERATION_MODE=marker, the files will be compiled using the flag -fembed-bitcode-marker, independent of the action phase.

So, if you want to enable the bitcode to every action (build and archive), the better way to do so is using the BITCODE_GENERATION_MODE setting you can do so either manual or by script.

Manual

On Build Settings, click on the + sign at the top to add a user-defined build setting with the name BITCODE_GENERATION_MODE, and set Debug to marker, Release to bitcode.

Edit schema as Release Then link the library.a file and get the build path get the library form Release folder

Script

xcodebuild BITCODE_GENERATION_MODE=bitcode OTHER_CFLAGS="-fembed-bitcode" -target "${PROJECT_NAME}" ONLY_ACTIVE_ARCH=NO -configuration ${CONFIGURATION} -sdk iphoneos BUILD_DIR="${BUILD_DIR}" BUILD_ROOT="${BUILD_ROOT}" clean build

not working... maybe you can comment on my post? Would be really grateful. https://stackoverflow.com/questions/54082111/compiled-framework-provides-bitcode-error-when-archiving — Viktor Vostrikov, Jan 07 '19 at 22:02
@JhonnyTawk, I upvoted your answer cause you're basically saying what this answer said: https://stackoverflow.com/a/38830497/9669133 ... yours is just a bit difficult to read but thanks. It pointed me in the right direction — PhillipJacobs, Dec 02 '19 at 09:09

score 11 · Accepted Answer · edited Nov 28 '19 at 21:15

11

Try to set Skip Install to YES and Enable Bitcode to Yes in framework build settings.

edited Nov 28 '19 at 21:15

Community

1
1

answered Dec 11 '18 at 00:09

Vitalii Gozhenko

9,220
2
48
66

@ViktorVostrikov how do you export your framework? Do you use Build->Archive? – Vitalii Gozhenko Jan 08 '19 at 15:04
No I did not used archived – Viktor Vostrikov Jan 09 '19 at 09:26
1

try to export framework using Build->Archive and then export build product to some folder – Vitalii Gozhenko Jan 09 '19 at 15:56
9

@VitaliyGozhenko i try to archive and export my framework via build product to some folder but exported products folder is empty – Siva Mar 01 '19 at 08:36

score 3 · Answer 3 · answered Aug 25 '20 at 12:15

if you do below commands

Enable Bitcode' set to 'YES' Adding
Flags' Adding 'BITCODE_GENERATION_MODE' with the value 'bitcode' set skip install to yes

they will not work until

flutter clean
flutter build ios

so that after you change build settings you need to run flutter build

score 1 · Answer 4 · answered Jan 21 '22 at 02:59

In my case, I have a unity project, and I want to export it to the ios library to integrate with another project. So I need to archive it -> Xcode show "library was built without full bitcode"

My solution for this case is:

Target -> Framework need archive -> Build setting -> Enable bitcode = NO

enter image description here

Hope it helpful

score 0 · Answer 5 · answered Feb 07 '20 at 11:52

0

Add to your project (no target), and for each project into your project (for example: Pods) one "User-Defined" in Build Settings:

BITCODE_GENERATION_MODE Debug = marker Release = bitcode

answered Feb 07 '20 at 11:52

vibroto

188
1
5

score 0 · Answer 6 · answered May 26 '20 at 03:21

0

Build Settings -> User-Defined -> Add Setting BITCODE_GENERATION_MODE, then set value: bitcode

answered May 26 '20 at 03:21

see2851

627
1
9
13

score 0 · Answer 7 · answered Oct 30 '20 at 14:08

0

Project settings -> Select Framework Target -> Build settings

add -fembed-bitcode in Other C Flags
click + Button -> Add User-Defined Setting

Key: BITCODE_GENERATION_MODE, value: bitcode
Build Active Architectures Only to Yes in Build settings.

answered Oct 30 '20 at 14:08

Lal Krishna

15,485
6
64
84

score -1 · Answer 8 · answered Jan 29 '20 at 13:50

-1

For the next soul that comes by and had everything enabled as described in OP but still failed to archive the app using it here's what worked for me:

Set up everything as stated in the OP.
Archive the product
Export it to your own filesystem
Find the exported mySadLittleFramework.xcarchive
Right click the file, chose Show Package Content
Product -> Library -> Frameworks will contain mySadLittleFramework.framework file
Drag/copy that file somewhere.
Add that file to your app project as framework.
Archive the app.

answered Jan 29 '20 at 13:50

maksa

374
5
16

1

No Library folder under Product – Vijay Kharage Apr 27 '20 at 13:06
If Skip Install is set to True for Release configuration, there won't be Library/Frameworks under Product – ambientlight Oct 20 '21 at 16:29
