Plot shaded time period (geom_rect) inside dplyr do loop with facet_wrap

Question

I'm having trouble getting a geom_rect to display a shaded area when using facet_wrap and the dplyr do(...) to generate the plots.

NOTE: The issue here may be related to a data structure issue. See this SO question for the current state of play.

The following minimal example uses the ggplot2 packages economics data and the NBER recession dates from the tis package.

Appreciate hints tips and incantations.

library(tis)
library(ggplot2)
# Prepare NBER recession start end dates.
start <- data.frame(date = as.Date(as.character(nberDates()[,"Start"]),"%Y%m%d"),
                    start= as.Date(as.character(nberDates()[,"Start"]),"%Y%m%d"))
end <- data.frame(date = as.Date(as.character(nberDates()[,"End"]),"%Y%m%d"),
                  end= as.Date(as.character(nberDates()[,"End"]),"%Y%m%d"))
dl <- economics %>%
        gather(metric, value, pce:unemploy ) %>%
        group_by(metric) %>%
        mutate(diff = value - lag(value, default=first(value))) %>%
        mutate(pct = diff/value) %>%
        gather(transform, value, value:pct ) %>%
        full_join(x=., y=start, by=c('date' = 'date')) %>%
        full_join(x=., y=end, by=c('date' = 'date')) %>%
        mutate(ymin = 0) %>%
        mutate(ymax = Inf)
# Check the start end dates are present
dl %>% group_by(metric,transform, start) %>% summarise( count=n())

pl <- dl %>%
        do(
          plots = ggplot(data=., aes(x = date, y = value)) +
                      geom_point() +
                      geom_rect(aes(xmin = start, xmax = end, ymin = ymin, ymax = ymax)) +
                      stat_smooth(method="auto",size=1.5) +
                      facet_wrap(~transform, scales="free_y")
          )

pl[[1,2]]

I tried running your code. "start" & "end" values are predominantly NA... What values do you intend to plot for each facet's `geom_rect()`? — Z.Lin, Jan 31 '18 at 07:03
Correct. There should be multiple regions shaded for each facet. I don't want to plot and values, just shade top to bottom. — Hedgehog, Jan 31 '18 at 20:36

score 0 · Answer 1 · answered Jan 31 '18 at 12:00

I have checked that the minimum and maximum dates for each group are the same (NA group is not plotted):

dl %>%
  group_by(transform) %>%
  summarise(min= min(start, na.rm =TRUE), max = max(start, na.rm =TRUE))#

A tibble: 4 x 3
  transform min        max
  <chr>     <date>     <date>
1 diff      1970-01-01 2008-01-01
2 pct       1970-01-01 2008-01-01
3 value     1970-01-01 2008-01-01
4 NA        1857-07-01 1960-05-01

Even if it is not the optimal solution, you can hard code both dates and use annotate to avoid opacity as geom_rect will draw multiple rectangles. I added alpha = 0.5 for transparency.

pl <- dl %>%
  do(
    plots = ggplot(data=., aes(x = date, y = value)) +
      geom_point() +
      annotate('rect', xmin = as.Date("1970-01-01"), xmax = as.Date("2008-01-01"),
               ymin = -Inf, ymax = Inf, alpha = 0.5) +
      stat_smooth(method="auto",size=1.5) +
      facet_wrap(~transform, scales="free_y")
  )
pl[[1,2]]

Thanks. Using `annotate` looks promising. But there are several shaded regions that need to be displayed, so I can't just take the first and last and hardcode them. — Hedgehog, Jan 31 '18 at 20:35
Hmm, I've just seen a wrinkle. It appears the values `end` are all `NA`. For some reason the `full_join` is not working for the `end` data frame. Looking into this. — Hedgehog, Jan 31 '18 at 20:45

score 0 · Accepted Answer · answered Jan 31 '18 at 23:51

Okay, the issue here is the construction of the data frame is non-trivial. Two uses of outer join does not provide the required structure.

# Prepare NBER recession start end dates.
recessions <- data.frame(start = as.Date(as.character(nberDates()[,"Start"]),"%Y%m%d"),
                    end= as.Date(as.character(nberDates()[,"End"]),"%Y%m%d"))

# Create the long format data frame
dl <- economics %>%
        gather(metric, value, pce:unemploy ) %>%
        group_by(metric) %>%
        mutate(diff = value - lag(value, default=first(value))) %>%
        mutate(pct = diff/value) %>%
        gather(transform, value, value:pct ) #%>%

# Build the data frame with start and end dates given in recessions
df1 <- dl %>%
        mutate(dummy=TRUE) %>%
        left_join(recessions %>% mutate(dummy=TRUE)) %>%
        filter(date >= start & date <= end) %>%
        select(-dummy)

# Build data frame of all other dates with start=NA and end=NA
df2 <- dl %>%
        mutate(dummy=TRUE) %>%
        left_join(recessions %>% mutate(dummy=TRUE)) %>%
        mutate(start=NA, end=NA) %>%
        unique() %>%
        select(-dummy)
# Now merge the two.  Overwirte NA values with start and end dates
dl <- df2 %>%
      left_join(x=., y=df1, by="date") %>%
      mutate(date, start = ifelse(is.na(start.y), as.character(start.x), as.character(start.y)),end = ifelse(is.na(end.y), as.character(end.x), as.character(end.y))) %>%
      mutate(start=as.Date(start), end=as.Date(end) ) %>%
      select(-starts_with("start."),-starts_with("end."),-ends_with(".y")) %>%
      setNames(sub(".x", "", names(.))) %>%
      mutate(ymin = -Inf) %>% #min(value)) %>%
      mutate(ymax = Inf) #max(value)) #%>%
# Check the start end dates are present
dl %>% group_by(metric,transform, start, end) %>% summarise( count = n() ) %>% print(n=180)

pl <- dl %>%
        group_by(metric) %>%
        do(
          plots = ggplot(data=., aes(x = date, y = value)) +
                      geom_point() +
                      # annotate('rect', xmin = start, xmax = end,
                      #          ymin = ymin, ymax = ymax, alpha = 0.5) +
                      geom_rect(aes(xmin = start, xmax = end, ymin = ymin, ymax = ymax), na.rm=TRUE) +
                      stat_smooth(method="auto",size=1.5) +
                      facet_wrap(~transform, scales="free_y")
          )

grid.draw(pl[[1,2]])
