Comparing interaction effect plots involving continuous variables from ggplot2 vs. base R using the effects package

Question

I want to plot interaction effects on my data set. I cannot share the full data set due to confidentiality reasons, but I have added the output of the effect() function, which can be substituted into the plot functions to reproduce my results

The interaction effect is between two continuous variables, varP and varL. The model is a binomial probit glm. I am using the effects() package.

Calling base R plot() yields the following chart:

plot(effect("varL:varP", hx.x), multiline = TRUE)

Calling ggplot yields an error, because ggplot2 cannot deal with continuous variables (Error: A continuous variable can not be mapped to linetype). So I decided to use cut() to transform the continuous into a categorical variable and redo the regression. Calling ggplot now yields the following plot:

ggplot(data.frame(effect("varL:varP_range", hx.x1))) +
 geom_line(aes(varL,fit,linetype=varP_range)) +
 theme_bw() +
 geom_point(aes(varL,fit, shape = varP_range), size = 4)

The effect() call results in the following data frame:

structure(list(varL = c(0, 4900000, 9800000, 1.5e+07, 2e+07,
0, 4900000, 9800000, 1.5e+07, 2e+07, 0, 4900000, 9800000, 1.5e+07,
2e+07, 0, 4900000, 9800000, 1.5e+07, 2e+07, 0, 4900000, 9800000,
1.5e+07, 2e+07, 0, 4900000, 9800000, 1.5e+07, 2e+07, 0, 4900000,
9800000, 1.5e+07, 2e+07, 0, 4900000, 9800000, 1.5e+07, 2e+07),
    varP_range = structure(c(1L, 1L, 1L, 1L, 1L, 2L, 2L, 2L,
    2L, 2L, 3L, 3L, 3L, 3L, 3L, 4L, 4L, 4L, 4L, 4L, 5L, 5L, 5L,
    5L, 5L, 6L, 6L, 6L, 6L, 6L, 7L, 7L, 7L, 7L, 7L, 8L, 8L, 8L,
    8L, 8L), .Label = c("(0,0.1]", "(0.1,0.2]", "(0.2,0.3]",
    "(0.3,0.4]", "(0.4,0.5]", "(0.5,0.6]", "(0.6,0.7]", "(0.7,0.8]",
    NA), class = "factor"), fit = c(0.0493753018091432, 0.0674980435061065,
    0.0903776022141578, 0.120475525568566, 0.155489425305936,
    0.0137978311572348, 0.0146948327184384, 0.0156415523658014,
    0.0167030042368772, 0.0177811545669692, 0.0283241226002015,
    0.0320688611660079, 0.0362132772188478, 0.0410808356583781,
    0.0462488565292175, 0.0376893470992477, 0.0434689290038736,
    0.0499436899670642, 0.0576329205782917, 0.0658761148111993,
    0.0461027343009466, 0.0491516310196363, 0.0523594626652533,
    0.0559432088894986, 0.0595689358953948, 0.0271243286792884,
    0.0288090021916312, 0.0305797680715237, 0.0325565879397662,
    0.0345556259933517, 0.0585874566843392, 0.0695486360371181,
    0.0820248510196267, 0.0970343941431089, 0.113280038210583,
    0.0209075509863267, 0.0315251673839061, 0.046253681947139,
    0.0674584535698224, 0.0942769896468577), se = c(0.026293040668674,
    0.0305781859107515, 0.0540612604209606, 0.0833019722980397,
    0.112487542810938, 0.0338534463222995, 0.0398771851800222,
    0.0731653210576088, 0.113913900015802, 0.15437353282528,
    0.0409108254231718, 0.0511475671899819, 0.0972355260310069,
    0.152187250282481, 0.206403037601197, 0.0130040830190118,
    0.0163131582968098, 0.03036212612247, 0.0472104967827754,
    0.0638665398985353, 0.00832820196917705, 0.0121268883535081,
    0.0232740805148284, 0.0361535949146859, 0.0487814483071773,
    0.0113362224665359, 0.0147098330114556, 0.027542020584634,
    0.0427882020481342, 0.057830481511906, 0.01601220706873,
    0.0215340145342622, 0.040911260287911, 0.0636748713064177,
    0.0860732173940343, 0.0419361989774607, 0.0474273262485864,
    0.085507397635156, 0.132979171779259, 0.180309829530109),
    lower = c(0.0443332267166309, 0.0600183728153565, 0.0743144400165266,
    0.0907939516369112, 0.108668209187463, 0.0116238722892657,
    0.012023490450893, 0.0108135425488573, 0.00937570172867644,
    0.00809811278621186, 0.0235056239743921, 0.025500658500369,
    0.0234608868503482, 0.0208470526400479, 0.0184481609874694,
    0.0356438216686479, 0.0406013691901053, 0.0441057429680943,
    0.0477084891588961, 0.0512971927819841, 0.0445466712620454,
    0.0467806376034436, 0.0476567944606461, 0.048393808464277,
    0.0490625016612481, 0.0257635103540086, 0.0269634191042765,
    0.0270321095726769, 0.0269061995593561, 0.0267392100653416,
    0.0550074959164803, 0.0640838876027606, 0.0705422656571929,
    0.0773047979652944, 0.0841065921246788, 0.017106637503393,
    0.025481438787035, 0.0321633667203674, 0.0395762352261805,
    0.0476311065775831), upper = c(0.0548650233126245, 0.0756784493915628,
    0.108885802402636, 0.156404820719125, 0.213976690522108,
    0.0163138248731072, 0.0178616891841985, 0.0222128708020368,
    0.0284614557616305, 0.0359832219741959, 0.0339378335208811,
    0.039975201853988, 0.0541535055907615, 0.0749340625856128,
    0.100655675600276, 0.0398297048294564, 0.0464977933470156,
    0.0563819985882714, 0.0691131684577491, 0.0834778881744663,
    0.0477021593328273, 0.0516176358055639, 0.0574233019439704,
    0.0643924091986213, 0.0717620710757599, 0.0285446055381808,
    0.0307584171780848, 0.0345046440925246, 0.0391516285886827,
    0.0441582201173176, 0.062347826961093, 0.0753653653841884,
    0.0948621519669373, 0.120230399782042, 0.149038245196167,
    0.0254001895885684, 0.0387079476679479, 0.0649209421145592,
    0.108535107340218, 0.16815843130232)), .Names = c("varL",
"varP_range", "fit", "se", "lower", "upper"), row.names = c("1",
"2", "3", "4", "5", "6", "7", "8", "9", "10", "11", "12", "13",
"14", "15", "16", "17", "18", "19", "20", "21", "22", "23", "24",
"25", "26", "27", "28", "29", "30", "31", "32", "33", "34", "35",
"36", "37", "38", "39", "40"), class = "data.frame")

My questions are:

1) How does effect() from the effects package transform the continuous into a categorical variable? How would this be replicated with ggplot()?

2) What is the reason that the lines in the base R plot all intersect at the same coordinate?

It's going to be much easier to answer this question with a reproducible example: unless the answer is easy/at the tip of someone's tongue, it's far easier to go through the example and see what's going on than to think through it on an abstract level. Also note that you're using the `effects()` package ... — Ben Bolker, Jan 07 '18 at 18:27
I still can't replicate this. I save your data frame as `eff`: neither `plot(eff)` nor `effects:::plot.eff(eff)` works to give me your plot.https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example and https://stackoverflow.com/questions/10454973/how-to-create-example-data-set-from-private-data-replacing-variable-names-and-l give some suggestions about generating a reproducible example for confidential data ... — Ben Bolker, Jan 07 '18 at 18:54
I realized that `ggplot` uses dataframes, while `plot` uses the original effect object. However, it is difficult to provide, as it has more than 18MB. I will try my best to create a better example. — deca, Jan 07 '18 at 19:09
did you really post the output of `dput(effect("varL:varP", hx.x))` ? that should have worked. (`dput()` should output a text version of the effect object that can be read back in to exactly recreate the original ...) — Ben Bolker, Jan 07 '18 at 19:28
No it was `dput(data.frame(effect("varL:varP", hx.x)))` - I also tried to apply `dput` directly to `effect()` but the object is 18MB large, so the `dput` output is too large to be shared here — deca, Jan 07 '18 at 20:16
OK, then you probably need to go back one step and construct a reproducible example. How about taking a 0.1% sample, making sure the same behaviour still occurs, and posting the output of `dput()` somewhere publicly accessible (self-contained example is preferable, but reproducible is better than non-reproducible) — Ben Bolker, Jan 07 '18 at 22:12

erocoar · Accepted Answer · 2018-01-09T09:52:44.283

To answer your first question: To define the factors, Effects uses

nice(seq(min(var), max(var), length.out=5))

where nice is defined like so (from here):

nice <- function (x, direction = c("round", "down", "up"), lead.digits = 1) {
  direction <- match.arg(direction)
  if (length(x) > 1){
    result <- sapply(x, nice, direction = direction, lead.digits = lead.digits)
    if (anyDuplicated(result)) result <- nice(x, direction=direction, lead.digits = lead.digits + 1)
    return(result)
  }
  if (x == 0)
    return(0)
  power.10 <- floor(log(abs(x), 10))
  if (lead.digits > 1)
    power.10 <- power.10 - lead.digits + 1
  lead.digit <- switch(direction, round = round(abs(x)/10^power.10),
                       down = floor(abs(x)/10^power.10), up = ceiling(abs(x)/10^power.10))
  sign(x) * lead.digit * 10^power.10
}

An example of using it:

library(effects)

set.seed(123)
x = rnorm(100)
z = rexp(100)
y = factor(sample(1:2, 100, replace=T))

test = glm(y~x+z+x*z, family = binomial(link = "probit"))

preddat <- matrix('', 25, 100)
preddat <- expand.grid(nice(seq(min(x), max(x), length.out=5)), nice(seq(min(z), max(z), length.out=5)))
colnames(preddat) <- c("x", "z")
predicts <- predict(test, preddat, type = "response")
dim(predicts) <- c(5,5)

effectspred <- pnorm(effect("x:z", test)$fit)
dim(effectspred) <- c(5,5)

all.equal(effectspred, predicts)

[1] TRUE

This is straight forward to use with ggplot:

library(tidyverse)

predicts %>% as.data.frame() %>%
  gather() %>% ggplot() + geom_line(aes(x = rep(nice(seq(min(x), max(x), length.out=5)), 5), y = value, color=key))

And regarding question 2, an intuitive way to think about it might be that, since the mean of Yhat doesn't change (predicted with fixed z), all the standard normal CDFs of the partial effects share the same intersection. E.g.

sapply(seq(0, 5, length.out = 15), function(k) {
  predict(test, data.frame(x = seq(-20, 20, length.out = 200), z = k), type = "response")}) %>%
  as.data.frame() %>% gather() %>% ggplot() +
  geom_line(aes(x = rep(seq(-20, 20, length.out = 200), 15), y = value, color = key))

Thanks, a truly great answer! Just one question, do you know how I can manually define the `factors` within `effects`? — deca, Jan 18 '18 at 11:56
Sorry for answering my own question, I figured it out myself in case someone faces a similar issue: By adding `xlevels = list(varP = c(10, 40, 80)` to the `effect` specification, one can define the factor values. — deca, Jan 18 '18 at 12:01
