I don't seem to understand the output of this block of code:

function fib(x) {
  return (x === 0 || x === 1) ? x : fib(x - 1) + fib(x - 2);
}

fib(7);
// output is 13

Here's my thinking process:

  • Pass int to the function and check if it's 0 or 1
  • If it's 0 or 1, proceed to return the passed value
  • If it's not 0 or 1, minus 1 from 7, then minus 2 from 7
  • Return the output which according through my (obviosly faulty) thinking would be 11

How does the function come to the result of 13?

  • 4
    You should learn about `recursion` that's what happening here. https://developer.mozilla.org/en-US/docs/Glossary/Recursion – Krusader Oct 15 '17 at 12:38
  • The function is unnecessarily hard to read. Would you appreciate a re-written form that's more readable? – glhrmv Oct 15 '17 at 12:41
  • 15
    @glhrmv Sorry, but how is this hard to read? It's a simple ternary operator. –  Oct 15 '17 at 12:43
  • 3
    Well it's easier to step through how something is working if it's on multiple lines, as opposed to jumbled up into one. Good luck using the [debugger](https://developer.mozilla.org/en-US/docs/Web/JavaScript/Reference/Statements/debugger) statement with this. – glhrmv Oct 15 '17 at 12:49
  • That's pretty simple recursion here. If `x` is 0 or 1 you return `x` or you return the sum of results of same function called twice by one and two less values of `x`. Of course you have to keep in mind that a function returns to where it was called from and code execution continues from that point on. – Redu Oct 15 '17 at 12:51
  • 2
    according to your function fib(7) = fib(6) + fib(5) if you put the values in there its fib(7) = 8 + 5 = 13 , how did you find 11 ? – Ömer Erden Oct 15 '17 at 12:53
  • Possible duplicate of [I can't understand this Fibonacci program flow](https://stackoverflow.com/questions/46273748/cant-understand-this-program-flow) (this question was originally about C#, but the core general understanding problem and answer seem to be the same to me) – Pac0 Oct 15 '17 at 19:23
  • @ÖmerErden 6 + 5 = 11, just missing the recursive call – Izkata Oct 15 '17 at 19:43

4 Answers4

5
--------------------------------------------------------------
| Step  | Function | Result                                 |
--------------------------------------------------------------
|  1    | f(7)     | f(6) + f(5) = a
|  2    |   a      | [f(5)+f(4)] + [f(4)+f(3)] = b
|  3    |   b      | [ [f(4)+f(3)] + [f(3)+f(2)] ] + [ [(f(3)+f(2)] + [f(2)+f(1)] ] = c
|  4    |   c      | [ [ [f(3)+f(2)] + [f(2)+f(1)] ] + [ [f(2)+f(1)] + [f(1) + f(0)] ] ] + [ [ [f(2)+f(1)]  + [f(1) + f(0)] ] + [ [f(1) + f(0)] + 1] ] = d
|  5    |   d      | [ [ [ [f(2)+f(1)]  + [f(1) + f(0)] ] + [ [f(1) + f(0)] +1] ] + [ [ [f(1) + f(0)] +1] + [1 + 0] ] ] + [ [ [ [f(1) + f(0)] +1]  + [1 + 0] ] + [ [1 + 0] + 1] ] = e
|  6    |   e      | [ [ [ [ [f(1) + f(0)] +1]  + [1 + 0] ] + [ [1 + 0] +1] ] + [ [ [1+ 0] +1] + [1 + 0] ] ] + [ [ [ [1 + 0] +1]  + [1 + 0] ] + [ [1 + 0] + 1] ] = f
|  7    |   f      | [ [ [ [ [1 + 0] +1]  + [1 + 0] ] + [ [1 + 0] +1] ] + [ [ [1+ 0] +1] + [1 + 0] ] ] + [ [ [ [1 + 0] +1]  + [1 + 0] ] + [ [1 + 0] + 1] ] = g

g= 13
Elif A.
  • 136
  • 8
3

If it's not 0 or 1, minus 1 from 7, then minus 2 from 7 Here is the fault. It will recurse, stacks will be built up (Meaning more fib() functions will be called). If you would like a pen and paper solution, here it is. Everything is done from left to right, mind that. I have shown a simple example for x=4. Try extending it for x=7. Will make the concept of recursion clearer to you!!

Fibonacci Recursion

Miraj50
  • 4,257
  • 1
  • 21
  • 34
1

Welcome to the beautifull world of recursion. It may be a hard concept to grasp, but very rewarding when you finally understand it.

@Elif A have written a nice table which shows exactly how the program run. However, when I learned recursion myself, I had this strategy where I "mapped" all the inputs on a piece of paper, starting with the inputs which gave me a value, instead of a function call. Then I build my way up. I really recommend this strategy, if you have a hard time understanding recursion.

Consider the following code

function factorial(n) {
      if (n == 1) {
             return 1;
       }
       else {
             return n*factorial(n-1)
       }
}

Lets say we want to find factorial(5). Instead of starting from the top, evaluating factorial(5), lets start at the bottom, building our way up to factorial(5). You'll see why this is a good intuitive way of understanding recursion.

factorial(1) = 1

factorial(2) = 2 * factorial(1) = 2 * 1 = 2

factorial(3) = 3 * factorial(2) = 2 * 3 = 6

factorial(4) = 4 * factorial(3) = 4 * 6 = 24

factorial(5) = 5 * factorial(4) = 5 * 24 = 120

Again, let me precise that this is just a way of understanding recursion. The table, which I mentioned is how the program actually run, and do the recursion.

Markus
  • 182
  • 5
  • Let's hope the OP has ES2015+. Otherwise, their JavaScript won't do tail call optimization, so that code's going to get rather inefficient for large args... – PM 2Ring Oct 15 '17 at 14:32
  • Just of pure curiosity, what is tail call optimization? – Markus Oct 15 '17 at 14:51
  • [What is tail call optimization?](https://stackoverflow.com/questions/310974/what-is-tail-call-optimization) – Cody Gray - on strike Oct 15 '17 at 15:18
  • 1
    @PM2Ring Even in engines that support TCO, this wouldn't apply. – Scimonster Oct 15 '17 at 15:44
  • I don't understand. All I tried was to simplify what recursion is. I need to read up on TCO, because I am not on the same page as you. – Markus Oct 15 '17 at 15:46
  • @PM2Ring: The tail "call" is to `*`, not to `factorial`, so I don't get your point? – Jörg W Mittag Oct 15 '17 at 17:46
  • @JörgWMittag Huh? IME, a tail call optimizer would optimize the recursive call to factorial in Markus's code. But I was actually talking about the OP's recursive Fibonacci code. I think you'd agree that without TCO or caching that a doubly recursive Fibonacci function gets pretty bad unless the arg is small. Try fib(30)... – PM 2Ring Oct 16 '17 at 00:42
  • @PM2Ring: A tail call optimizer will optimize the tail call. The tail call is (roughly) "the last call". `factorial` is not the last call, `*` is executed afterwards. The tail call is to `*`, not to `factorial`. – Jörg W Mittag Oct 16 '17 at 06:59
0

You just forgot that what is returned if fib(6)+fib(5), not 6+5

This schema can help you understand the logic and order of calculations for fib(5) :

recursive Fibonacci function for fib(5)

Try to draw the same diagram for fib(6), and then for fib(7), and you will understand recursion much better.

And also quickly conclude that this is a terribly inefficient algorithm to use if your goal is actually calculating Fibonacci numbers

(taken and modified image from an other answer of mine on a related question, diagram originally from http://composingprograms.com/pages/28-efficiency.html)

Pac0
  • 21,465
  • 8
  • 65
  • 74
